Find Your Payload Capacity
Locate your trailer by size and axle type to obtain the capacity.
Single-Axle Trailers with 3500-lb. Axles
| Size | Empty Weight | Tongue Weight | Payload Capacity |
|---|---|---|---|
| 6 x 12 | 1200 | 180 | 2300 |
Tandem-Axle Trailers with 3500-, 5200- and 7000-lb. Axles
| Size | Empty Weight | Tongue Weight | Payload Capacity 3500 lb. | Payload Capacity 5200 lb. | Payload Capacity 7000 lb. |
|---|---|---|---|---|---|
| 6 x 12 | 1800 | 270 | 5200 | 8600 | NA |
| 6 x 14 | 2060 | 309 | 4940 | 8340 | NA |
| 7 x 12 | 1960 | 294 | 5040 | 8440 | 12,040 |
| 7 x 14 | 2120 | 318 | 4880 | 8280 | 11,880 |
| 7 x 16 | 2260 | 339 | 4740 | 8140 | 11,740 |
| 7 x 18 | 2480 | 372 | 4520 | 7920 | 11,520 |
| 7 x 20 | 2640 | 396 | 4360 | 7760 | 11,360 |
| 8.5 x 14 | 2600 | 400 | 4400 | 7800 | 11,400 |
| 8.5 x 16 | 2800 | 420 | 4200 | 7600 | 11,200 |
| 8.5 x 18 | 3000 | 450 | 4000 | 7400 | 11000 |
| 8.5 x 20 | 3200 | 480 | 3800 | 7200 | 10,800 |
| 8.5 x 22 | 3400 | 510 | 3600 | 7000 | 10,600 |
| 8.5 x 24 | 3600 | 540 | 3400 | 6800 | 10,400 |
26-ft. and Up Tandem-Axle Trailers with 5200- and 7000-lb. Axles
| Size | Empty Weight | Tongue Weight | Payload Capacity 5200 lb. | Payload Capacity 7000 lb. |
|---|---|---|---|---|
| 8.5 x 26 | 4000 | 600 | 6400 | 10,000 |
| 8.5 x 28 | 4200 | 630 | 6200 | 9800 |
| 8.5 x 30 | 4400 | 660 | 6000 | 9600 |
| 8.5 x 32 | 4600 | 690 | 5800 | 9400 |
| 8.5 x 34 | 4800 | 720 | 5600 | 9200 |
